TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage

TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage

Brand Name: Iter
Model Number: TP232
MOQ: 1set
Payment Terms: L/C,T/T,Western Union
Supply Ability: 1000sets/month
Detail Information
Place of Origin:
Guangdong
Certification:
CE
Lifting Capacity:
3200kg
Release System:
Electrical Or Manual
Voltage:
220V/380V/as Your Request
Color:
Yellow/blue/red/green
Terms:
EXW/FOB/CIF
Volume:
3.5cbm
Packaging Details:
export standard, steel frame and carton
Supply Ability:
1000sets/month
Highlight:

Hydraulic 2 Post Car Lift

,

Workshop 2 Post Car Lift

,

Garage 2 Post Car Lift

Product Description
TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage
Product Specifications
Attribute Value
Lifting capacity 3200kg
Release system Electrical or manual
Voltage 220V/380V/as your request
Color yellow/blue/red/green
Terms EXW/FOB/CIF
Volume 3.5cbm
Product Features
  • Practical and adaptable design suitable for various environments from private garages to commercial buildings, with simple installation requiring no specialized expertise.
  • User-friendly operation with intuitive controls for effortless vehicle lifting and parking, suitable for personal, commercial, or industrial use.
  • Customizable multi-unit configurations using shared posts for efficient dual or triple parking solutions, reducing installation complexity and costs.
  • Six dynamic unlocking positions with adjustable heights from 1600mm to 2100mm to accommodate different vehicle heights.
  • Infrared photoelectric detection technology for obstacle detection and automatic stopping when necessary for enhanced safety.
  • Automatic locking mechanism ensures vehicle stability and security during operation.
  • Two-stage inverted hydraulic lifting system with Italian-imported sealing rings for superior oil retention and durability.
  • DC24V control voltage system reduces electrical risks for a safer working environment.
Technical Specifications
Lifting Capacity 6400Lbs/3200kg
Lifting Height 2100mm
Lifting Time 60 seconds
Min Height 5"/125mm
Column height 3500mm
Platform size 4173*2100mm
Motor Voltage 220V/380V
Frequency 50Hz or 60Hz
Phase 1Ph/3Ph
Net Weight 2200bs/1100kg
Product Details
TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage 0
TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage 1
TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage 2
Safety lock
TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage 3
Limit switch
TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage 4
Base design
TP232 Hydraulic 2 Post Car Lift For Stable Operation At Workshop Or Garage 5
Control box
