T240M Two Post Gantry Car Lifting Equipment with Advanced Lifting Technology

T240M Two Post Gantry Car Lifting Equipment with Advanced Lifting Technology

Brand Name: Iter
Model Number: T240M
MOQ: 1set
Payment Terms: L/C,T/T,Western Union
Supply Ability: 1000sets/month
Detail Information
Place of Origin:
Guangdong
Certification:
CE
Lifting Capacity:
4000kg
Release System:
Manual
Voltage:
220V/380V/as Your Request
Color:
Yellow/blue/red/green
Terms:
EXW/FOB/CIF
Volume:
1.5cbm
Packaging Details:
export standard, steel frame and carton
Supply Ability:
1000sets/month
Highlight:

Gantry Car Lifting Equipment

,

Two Post Car Lifting Equipment

,

Gantry Two Post Car Lift

Product Description
T240M Two Post Gantry Car Lifting Equipment with Advanced Lifting Technology
Product Specifications
Attribute Value
Lifting Capacity 4000kg
Release System Manual
Voltage 220V/380V/as your request
Color Yellow/Blue/Red/Green
Terms EXW/FOB/CIF
Volume 1.5cbm
Product Features
  • Spacious undercarriage design for hassle-free mechanic access
  • Manual safety release system on both sides with optional single-point release
  • Premium Japanese and U.S. oil seals for smooth, long-lasting cylinder operation
  • Asymmetric lifting arms provide extra working room for wider vehicles
  • Durable motor available with standard iron casing or upgraded aluminum variant
Technical Specifications
Specification Value
Lifting Capacity 9000lbs/4000kg
Lifting Height 71"/1800mm
Lifting Time 50 seconds
Overall Height 112"/2856mm
Overall Width 138"/3500mm
Width between Columns 109"/2760mm
Motor Voltage 220V/380V
Frequency 50Hz/60Hz
Phase 1ph/3ph
Net Weight 1439lbs/653kg
Product Images
T240M Two Post Gantry Car Lifting Equipment with Advanced Lifting Technology 0
T240M Two Post Gantry Car Lifting Equipment with Advanced Lifting Technology 1
T240M Two Post Gantry Car Lifting Equipment with Advanced Lifting Technology 2
3+2 design stranger arms
T240M Two Post Gantry Car Lifting Equipment with Advanced Lifting Technology 3
Durable steel oil tank
