TP227 Dynamic Locking 2 Post Lift With Multi Level Parking Support

TP227 Dynamic Locking 2 Post Lift With Multi Level Parking Support

Brand Name: Iter
Model Number: TP227
MOQ: 1set
Payment Terms: L/C,T/T,Western Union
Supply Ability: 1000sets/month
Detail Information
Place of Origin:
Guangdong
Certification:
CE
Lifting Capacity:
2700kg
Release System:
Electrical Or Manual
Voltage:
220V/380V/as Your Request
Color:
Yellow/blue/red/green
Terms:
EXW/FOB/CIF
Volume:
3.5cbm
Packaging Details:
export standard, steel frame and carton
Supply Ability:
1000sets/month
Highlight:

Dynamic Locking 2 Post Lift

,

Parking Support 2 Post Lift

,

Multi Level Support 2 Post Lift

Product Description
TP227 Dynamic Locking 2 Post Lift With Multi Level Parking Support
Key Specifications
Lifting Capacity 2700kg (5940lbs)
Release System Electrical or manual
Voltage 220V/380V (customizable)
Color Options Yellow/Blue/Red/Green
Shipping Terms EXW/FOB/CIF
Volume 3.5cbm
Product Features
Special SUV parking design with smooth lifting operation and enhanced safety features to prevent unexpected drops
Versatile multi-use design compatible with various parking environments, featuring simple installation and user-friendly controls
Space-efficient post-sharing capability allowing 2-3 lifts to operate as a single unit, reducing installation costs
Adjustable locking heights (1600mm-2100mm) with six-position dynamic unlocking system for flexible parking solutions
Infrared photoelectric detection system for obstacle identification and accident prevention
Two-stage inverted hydraulic system with high-performance Italian sealing rings for leak-free operation
Technical Specifications
Lifting Capacity 5940Lbs/2700kg
Lifting Height 2100mm
Lifting Time 2m/min
Min Height 5"/125mm
Column Height 3500mm
Platform Size 4173*2100mm
Motor Voltage 220V/380V
Frequency 50Hz or 60Hz
Phase 1Ph/3Ph
Net Weight 2310lbs/1050kg
System Components
TP227 Dynamic Locking 2 Post Lift With Multi Level Parking Support 0 TP227 Dynamic Locking 2 Post Lift With Multi Level Parking Support 1 TP227 Dynamic Locking 2 Post Lift With Multi Level Parking Support 2 TP227 Dynamic Locking 2 Post Lift With Multi Level Parking Support 3
