TP232 Electric Controlled Car Lifting Equipment 2 Post Parking Lift With Remote Access

TP232 Electric Controlled Car Lifting Equipment 2 Post Parking Lift With Remote Access

Brand Name: Iter
Model Number: TP232
MOQ: 1set
Payment Terms: L/C,T/T,Western Union
Supply Ability: 1000sets/month
Detail Information
Place of Origin:
Guangdong
Certification:
CE
Lifting Capacity:
3200kg
Release System:
Electrical Or Manual
Voltage:
220V/380V/as Your Request
Color:
Yellow/blue/red/green
Terms:
EXW/FOB/CIF
Volume:
3.5cbm
Packaging Details:
export standard, steel frame and carton
Supply Ability:
1000sets/month
Highlight:

Electric Controlled Car Lifting Equipment

,

Remote Access Car Lifting Equipment

,

Electric 2 Post Parking Lift

Product Description
TP232 Electric Controlled Car Lifting Equipment 2 Post Parking Lift With Remote Access
Key Specifications
Lifting Capacity
3200kg
Release System
Electrical or manual
Voltage
220V/380V/as your request
Color Options
Yellow/Blue/Red/Green
Terms
EXW/FOB/CIF
Volume
3.5cbm
Product Features
  • Space-saving two-post design specifically engineered for SUVs and taller vehicles, utilizing high-strength materials for reliable operation
  • Smart post-sharing feature allows two- or three-unit combinations for optimized space utilization and cost efficiency
  • Six-position dynamic locking system with adjustable heights between 1600mm and 2100mm
  • Infrared photoelectric detection system for real-time obstruction detection and automatic motion stopping
  • Automatic locking feature stabilizes parked vehicles to prevent unintended movement
  • Two-stage inverted hydraulic cylinder with premium Italian sealing rings prevents oil leaks
  • DC24V control voltage system enhances operator safety while maintaining stable performance
  • Minimal installation effort required with intuitive controls for seamless operation
Technical Specifications
Lifting Capacity 6400Lbs/3200kg
Lifting Height 2100mm
Lifting Time 60 seconds
Min Height 5"/125mm
Column Height 3500mm
Platform Size 4173*2100mm
Motor Voltage 220V/380V
Frequency 50Hz or 60Hz
Phase 1Ph/3Ph
Net Weight 2200bs/1100kg
