T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment

T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment

Brand Name: Iter
Model Number: T400D
MOQ: 1 set
Payment Terms: L/C,T/T,Western Union
Supply Ability: 500 sets/month
Detail Information
Place of Origin:
Guangdong
Certification:
CE
Color:
Red/blue/yellow/grey
Voltage:
380V/220V As Your Request
Volume:
3cbm
Lifting Capacity:
8800bls /4000kg
Warranty:
1 Year
Brand:
Iter/OEM
Packaging Details:
steel frame and carton
Supply Ability:
500 sets/month
Highlight:

T400D Hydraulic Scissor Lift

,

Wheel Alignment Hydraulic Scissor Lift

,

Cars Wheel Hydraulic Scissor Lift

Product Description
T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment
Product Specifications
Attribute Value
Color red/blue/yellow/grey
Voltage 380V/220V as your request
Volume 3cbm
Lifting capacity 8800lbs /4000kg
Warranty 1 year
Brand Iter/OEM
Product Features
  • Embedded floor installation provides flush fit for enhanced accessibility, safety, and workspace efficiency
  • Advanced engineering enables precise vehicle alignment and thorough chassis examinations
  • Adjustable turntable accommodates multiple vehicle sizes and models
  • 500mm maximum lifting height with extendable central jack for trucks and larger vehicles
  • Aluminum-cased motor for efficient heat dissipation during continuous heavy-duty operation
  • Integrated self-locking safety mechanism prevents sudden drops
  • Pneumatic release system reduces operational noise for quieter work environments
Technical Specifications
Specification Value
Lifting Capacity 8800Lbs/4000kg
Secondary Lifting Height 18.5"/470mm
Lifting Height 78.35"/1990mm
Lifting Time for Jack 20 seconds
Lifting Time for Large Scissor 30 seconds
Min Height 13"/330mm
Air Source Pressure 5-6kg/cm²
Platform Width 24"/620mm
Width between two platforms 33.5"/850mm
Overall Length 177.17"/4500mm
Motor Voltage 220V/380V
Frequency 50Hz or 60Hz
Phase 1Ph/3Ph
Net Weight 4091Lbs/1856kg
Product Images
T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment 0
Safety lock system
T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment 1
Secondary jacks
T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment 2
Different sizes for turntable cover
T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment 3
Control box
T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment 4
Aluminum pump station for efficient cooling
T400D Premium Hydraulic Scissor Lift For Different Cars Wheel Alignment 5
Circuit board
