T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds

T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds

Brand Name: Iter
Model Number: T240M-1
MOQ: 1set
Payment Terms: T/T,Western Union
Supply Ability: 1000 sets/month
Detail Information
Place of Origin:
China
Certification:
CE
Color:
Red/blue/yellow/grey
Voltage:
220V/380V/As Your Request
Volume:
1.5 Cbm
Release System:
Single Point Manual Release
Payment Terms:
EXW/FOB/CIF
Lifting Capacity:
8800lbs
Packaging Details:
steel frame with carton
Supply Ability:
1000 sets/month
Highlight:

Hydraulic 2 Post Vehicle Lift

,

T240M-1 2 Post Vehicle Lift

,

Quick Turnarounds 2 Post Vehicle Lift

Product Description
T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds
Product Specifications
Color red/blue/yellow/grey
Voltage 220V/380V/As your request
Volume 1.5 cbm
Release System single point manual release
Payment Terms EXW/FOB/CIF
Lifting Capacity 8800lbs
Product Description

T240M-1 Efficient Hydraulic 2-Post Vehicle Lift for Quick Turnarounds

  • The open floor layout improves overall workflow by eliminating any hindrance during vehicle servicing.
  • The one-sided manual safety lock release provides a fast and straightforward method to disengage the lock.
  • Engineered for perfection, oil seals from Japan and the USA provide unparalleled performance in the hydraulic system.
  • The design features a robust cast-iron motor cover to ensure long-term reliability, with a supplementary option for an aluminum cover upgrade.
  • The lift features an innovative off-center arm structure that maximizes space for vehicles with a 2860mm width specification.
  • For enhanced hydraulic control, users can choose an optional imported pump that meets rigorous performance standards.
  • To cater to different global markets, the system supports an optional multi-voltage power supply option.
Technical Data
Lifting Capacity 8800lbs/4000kg
Lifting Height 71"/1800mm
Lifting Time 50seconds
Overall Height 112"/2856mm
Overall Width 138"/3500mm
Width between Columns 112"/2860mm
Motor Voltage 220V/380V
Frequency 50Hz/60Hz
Phase 1ph/3ph
Net weight 1439lbs/653kg
Product Details
T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds 0
Single point release
T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds 1
3+2 arm design
T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds 2
Optional rubber support
T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds 3
Carriage design
T240M-1 Hydraulic 2 Post Vehicle Lift For Quick Turnarounds 4
