T240M-1 2 Post Hoist User Friendly With 50seconds Lifting Time

T240M-1 2 Post Hoist User Friendly With 50seconds Lifting Time

Brand Name: Iter
Model Number: T240M-1
MOQ: 1set
Payment Terms: T/T,Western Union
Supply Ability: 1000 sets/month
Detail Information
Place of Origin:
China
Certification:
CE
Color:
Red/blue/yellow/grey
Voltage:
220V/380V/As Your Request
Volume:
1.5 Cbm
Release System:
Single Point Manual Release
Payment Terms:
EXW/FOB/CIF
Lifting Capacity:
8800lbs
Packaging Details:
steel frame with carton
Supply Ability:
1000 sets/month
Highlight:

T240M-1 2 Post Hoist

,

User Friendly 2 Post Hoist

,

50seconds Lifting Time 2 Post Hoist

Product Description
T240M-1 2 Post Hoist - User Friendly With 50 Seconds Lifting Time
Product Specifications
Color: red/blue/yellow/grey
Voltage: 220V/380V/As your request
Volume: 1.5 cbm
Release System: single point manual release
Payment Terms: EXW/FOB/CIF
Lifting Capacity: 8800lbs
Product Features
  • Clear and accessible floor area simplifies vehicle inspections and repairs
  • Single-point manual release system for quick operator access to controls
  • High-performance oil cylinder with internationally sourced oil seals
  • Asymmetric arm design accommodates vehicles with wider wheel tracks up to 2860mm
  • Optional high-performance imported pump available
  • Durable cast-iron motor cover with optional lightweight aluminum alternative
  • Multi-voltage power supply option for flexible installation worldwide
Technical Specifications
Lifting Capacity 8800lbs/4000kg
Lifting Height 71"/1800mm
Lifting Time 50 seconds
Overall Height 112"/2856mm
Overall Width 138"/3500mm
Width between Columns 112"/2860mm
Motor Voltage 220V/380V
Frequency 50Hz/60Hz
Phase 1ph/3ph
Net Weight 1439lbs/653kg
Product Details
T240M-1 2 Post Hoist User Friendly With 50seconds Lifting Time 0
T240M-1 2 Post Hoist User Friendly With 50seconds Lifting Time 1
T240M-1 2 Post Hoist User Friendly With 50seconds Lifting Time 2
Single point release
T240M-1 2 Post Hoist User Friendly With 50seconds Lifting Time 3
3+2 arm design
T240M-1 2 Post Hoist User Friendly With 50seconds Lifting Time 4
Optional rubber support
