T8445A Brake Drum Disc Lathe 30/54/80 r/min For Different Cars

T8445A Brake Drum Disc Lathe 30/54/80 r/min For Different Cars

Brand Name: Iter
Model Number: T8445A
MOQ: 1 set
Payment Terms: L/C,T/T,Western Union
Supply Ability: 1000 sets/ month
Detail Information
Place of Origin:
China
Certification:
CE
Color:
Blue/red
Rotating Speed Of Work-pieces:
30/54/80 R/min
Brake Drum Diameter:
7.2" - 18" /180-450mm
Max Travel Of Tools:
68"/170mm
Feeding Capacity:
0.16/0.3mm/r
Warranty:
1 Year
Packaging Details:
plywood boxes
Supply Ability:
1000 sets/ month
Highlight:

T8445A Brake Drum Disc Lathe

,

80 r/min Disc Lathe

,

Cars Brake Drum Disc Lathe

Product Description
T8445A Brake Drum Disc Lathe 30/54/80 r/min For Different Cars
Key Specifications
Color Options Blue/Red
Rotating Speed 30/54/80 r/min
Brake Drum Diameter Range 7.2" - 18" (180-450mm)
Max Travel of Tools 68" (170mm)
Feeding Capacity 0.16/0.3mm/r
Warranty 1 Year
High-Efficiency Brake Drum and Disc Lathe

The T8445A is a versatile brake lathe designed for professional automotive workshops, offering precision machining for a wide range of vehicle brake systems.

Product Features
  • Wide Processing Range: Handles brake drums (180-450mm) and discs (up to 420mm) for various vehicle types
  • Variable Spindle Speeds: Three selectable speeds (30, 54, 80 r/min) for optimal machining performance
  • Precision Feed Rates: Dual feed options (0.16 mm/r and 0.3 mm/r) for controlled material removal
  • Universal Compatibility: Processes brake components for passenger cars to commercial trucks
  • User-Friendly Operation: Intuitive control panel with clear visual feedback for efficient adjustments
  • Quick Setup: Rapid adaptation between different brake disc sizes minimizes workshop downtime
  • Premium Tool Post: Enhanced design for smooth operation with high-end vehicle brands
Technical Specifications
Model T8445
Brake Drum Capacity 180-450mm
Brake Disc Capacity ≤420mm
Rotating Speed 30/54/80 r/min
Max Tool Travel 170mm
Motor Power 1.5/1.1kw
Gross Weight 290KG
Package Dimensions 690×890×880mm
Standard Parts
