X6 Workshop 3D Wheel Alignment Machine With High Speed Processing

X6 Workshop 3D Wheel Alignment Machine With High Speed Processing

Brand Name: Iter
Model Number: X6
MOQ: 1set
Payment Terms: T/T,Western Union,L/C
Supply Ability: 500 sets/month
Detail Information
Place of Origin:
Guangzhou,China
Certification:
CE
Screen:
Double
Wheel Size:
13"-24"
Track Width:
1200-1800mm
Wheel Base:
2000-3200mm
Baseline Distance:
2300-2700mm
Support Columun Height:
2200mm
Packaging Details:
plywood box
Supply Ability:
500 sets/month
Highlight:

3D Wheel Alignment Machine

,

X6 Wheel Alignment Machine

,

Workshop Wheel Alignment Machine

Product Description
X6 Workshop 3D Wheel Alignment Machine With High Speed Processing
Screen
double
Wheel size
13"-24"
Track width
1200-1800mm
Wheel base
2000-3200mm
Baseline distance
2300-2700mm
Support column height
2200mm
Product Overview

The X6 Workshop-Ready 3D Wheel Alignment Machine features high-speed processing and double screens for efficient vehicle alignment operations.

Key Features
  • High-Precision 3D Technology: Equipped with high-resolution optical technology for perfect alignment data accuracy.
  • Advanced Alignment Sensors: Next-generation sensors provide precise diagnostics of wheel and suspension angles.
  • User-Friendly Interface: Streamlined controls enable technicians to make quick adjustments with ease.
  • Automatic Calibration: Built-in self-calibration maintains consistent results with every use.
  • Wide Vehicle Compatibility: Versatile design accommodates a broad range of vehicle models.
  • Quick Scanning: Delivers immediate, accurate readings for maximum efficiency.
  • Full Rotation Monitoring: Tracks all aspects of wheel movement for ultimate precision.
Technical Specifications
Wheel size:
13"-24"
Track width:
1200-1800 mm
Wheel Base:
2000-3200 mm
Baseline Distance:
2300-2700 mm (From Camera Beam to Turn-table center)
Camera Offset Height:
450-800 mm (From Target center to Camera)
Camera Beam Height:
1700-2100 mm
Camera Beam Length:
2600 mm
Support Column Height:
2200 mm
Power Requirements:
110/220v, 1ph, 60Hz
Monitor:
22" LCD
Operation System:
Windows 7/Windows 8
Printer:
AOC Color Ink Jet
