The Tire Changer for Heavy-duty Truck Tires Designed for Safety Efficiency and Versatility in Workshop Applications

Name

The Tire Changer for Heavy-duty Truck Tires Designed for Safety Efficiency and Versatility in Workshop Applications

Brand Name: Iter
Model Number: XT-56
MOQ: 1set
Payment Terms: T/T,Western Union
Supply Ability: 1000 sets/month
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE
Color:
Blue,red Or Grey
Rim Clamping Outside:
14"-26"
Max. Wheel Weight:
500kg
Max. Wheel Width:
780mm
Max. Tire Diamter:
1600mm
Operation Control Voltage:
24V
Packaging Details:
carton and plywood box
Supply Ability:
1000 sets/month
Product Description
Heavy-Duty Truck Tire Changer

Professional-grade tire changing equipment designed for safety, efficiency, and versatility in workshop applications.

Key Specifications
Attribute Value
Color Options Blue, Red or Grey
Rim Clamping Range 14"-26"
Max. Wheel Weight 500kg
Max. Wheel Width 780mm
Max. Tire Diameter 1600mm
Operation Control Voltage 24V
Product Features
  • Flexible low-pressure control handle for precise operational pressure adjustment and enhanced safety
  • 24V power supply for safe operation with reduced electrical hazards and stable performance
  • Universal assembly arm with swinging disc and hook for handling 14"-26" wheels
  • Hydraulically driven lift hips and clamps for smooth, controlled lifting and secure clamping
  • Optional Italian pump upgrade for superior hydraulic performance and reliability
Technical Specifications
Model:
XT-26
Rim Diameter:
14"-26"
Max. Wheel Weight:
500KG
Max. Wheel Width:
780mm
Max. Tire Diameter:
1600mm
Hydraulic Pump Motor:
1.5kw 380V-3Ph (220V Optional)
Gearbox Motor:
2.2kw 380v-3ph (220v optional)
Bead Breaker Force:
2500kg
Operation Control Voltage:
24V
Max. Torque:
6457N.M
Weight:
517kg
Package Size:
2500*2000mm
Voltage:
220v/420V/380v
The Tire Changer for Heavy-duty Truck Tires Designed for Safety Efficiency and Versatility in Workshop Applications 0 The Tire Changer for Heavy-duty Truck Tires Designed for Safety Efficiency and Versatility in Workshop Applications 1
