Heavy Duty Car Truck Hydraulic Tire Changer With Adjustable Clamping

Heavy Duty Car Truck Hydraulic Tire Changer With Adjustable Clamping

Brand Name: Iter
Model Number: XT-56
MOQ: 1set
Payment Terms: T/T,Western Union
Supply Ability: 1000 sets/month
Detail Information
Place of Origin:
China
Certification:
CE
Color:
Blue,red Or Grey
Rim Clamping Outside:
14"-56"
Max. Wheel Weight:
2000kg
Max. Wheel Width:
1200mm
Max. Tire Diamter:
2500mm
Operation Control Voltage:
24V
Packaging Details:
carton and plywood box
Supply Ability:
1000 sets/month
Highlight:

Truck Hydraulic Tire Changer

,

Car Hydraulic Tire Changer

,

Adjustable Clamping Hydraulic Tire Changer

Product Description
Heavy Duty Car Truck Hydraulic Tire Changer With Adjustable Clamping
Product Overview

This heavy-duty hydraulic truck tire changer is designed for demanding applications, featuring robust construction and advanced functionality for professional automotive service environments.

Key Specifications
Available Colors:
Blue, Red or Grey
Rim Clamping Range:
14" - 56"
Maximum Wheel Weight:
2000kg
Maximum Wheel Width:
1200mm
Maximum Tire Diameter:
2500mm
Operation Control Voltage:
24V
Advanced Features
  • Wide Rim Capacity & Adjustable Clamping: Accommodates rims from 14" to 56" with self-centering hydraulic clamping that protects delicate alloy finishes.
  • Multi-Speed Bi-Directional Chuck: Offers selectable speeds and bi-directional rotation for precise control during tire mounting and removal.
  • Automated Mount/Demount Arm: Enables rapid, error-free operation for increased productivity.
  • Ergonomic Controls: Features intuitive foot pedals, joystick or remote controls for single-operator use and enhanced safety.
  • Integrated Inflation System: Includes inflation gauges, bleed valves, and dedicated inflation pedals for proper tire pressure management.
  • Optional Italian Hydraulic Pump: Available upgrade provides enhanced power and smoother tire-changing performance.
Technical Specifications
Model XT-56
Rim Diameter 14" - 56"
Max Wheel Weight 2000KG
Max Wheel Width 1200mm
Max Tire Diameter 2500mm
Hydraulic Pump Motor 3.3kw/4.0kw 380V-3Ph (220V Optional)
Gearbox Motor 3.3kw/4.0kw 380v-3ph (220v optional)
Operation Control Voltage 24V
Weight 1175kg
Package Size 2500*2000mm
Voltage 220v/420V/380v
